Double-Sided Ultra High Bond Foam Tape 79 Mil, White

DCFAUHB80W Ultra High Bond Double Coated Tape is engineered with a white foamed acrylic system, delivering exceptional bonding properties suitable for demanding applications, especially in the transportation industry. With excellent adhesion, high shear strength, and resistance to chemicals, UV, and solvents, this tape ensures reliable performance in various indoor and outdoor settings.

Key Features: Double-Sided White Ultra-High Bond Foam Tape – 80 Mil to 120 Mil x 18 yards | DCFAUHB

• White foamed acrylic system for exceptional bonding
• Excellent adhesion to a variety of surfaces
• Conformable foam core for versatility
• Chemical, UV, and solvent resistant

Application Tips:

• Avoid contaminating the acrylic adhesive after removing the release liner
• Apply a minimum pressure of 15 pounds per inch of tape width for optimal bond strength
• Allow 1 to 24 hours for dwell time to achieve maximum adhesion

Product Applications:

• Suitable for transportation, appliance, electronics, construction, signage, and general industrial sectors
• Used in automotive aftercare market and body shops for crash repair
• Ideal for mounting and fixing car side moldings, emblems, and other exterior trim parts
• Commonly used in illuminated displays, signage, laminated safety glass, and architectural applications
• Great for cost-effective attachment of trim and moldings

Technical Properties:

• Adhesive: Ultra-high bond acrylic
• Carrier/Backing: Foamed acrylic
• Thickness: 78.2 mils
• Adhesion: 124.8 ounces per inch
• Tensile Strength: 93 pounds per inch (longitudinal)
• Service/Operating Temperature: -40¬¨‚àûF to 212¬¨‚àûF
• Short Term Temperature Resistance: up to 320¬¨‚àûF
• Dynamic Shear Strength: 79 pounds per square inch
• Core: 3" Diameter

Additional Information:

• Alternative to: 3M 4912; ADCO 4955; Hi-Bond 4200W.

Note: Specifications are those given by manufacturers and are not tested for accuracy.
